mobile bedside X-ray machine (MST-X50BY)
Tel：
0754-88481863Product Introduction:
The MST-X50BY machine is a mobile bedside X-ray machine that
uses full wave rectification and a combination X-ray head.
The frame adopts a cantilever structure, and
the head positioning is light and convenient.
The machine adopts an electric beam limiter,
which can conveniently and correctly control the radiation
field of X-rays. The whole machine is compact, portable,
easy to operate, safe and reliable, and can be used for
X-ray photography in various hospitals,
clinics, wards or operating rooms.
| Main technical indicators | |
| Power supply conditions | Voltage: 180-240V Frequency: 50Hz Internal resistance: ≤ 1 Ω Rated value:5kVA Current: 15A higher photography output |
| Timer | 0.08-6.32 electronic mode |
| X-ray machine head focus to the highest position of the plane | >1820mm |
| X-ray machine head focus to the lowest position of the plane | >550mm |
| collimator | Maximum film size: 1000mm Focal length: 430 x 430mm |
| Maximum remote control distance | 6M |
| X-ray tube focus | 2.3 x 2.3 |
| Unit movement force | <5kg |
| Net weight of the entire machine | 90kg |
