mobile bedside X-ray machine (MST-X70BY)
Tel：
0754-88481863Product Introduction:
This machine is an MST-X70BY 70mA mobile X-ray machine,
which adopts full wave rectification and a combination
X-ray machine head. The frame adopts a cantilever structure,
and the machine head positioning is
lightweight and convenient. This machine adopts
an electric beam limiter, which can conveniently
and correctly control the radiation field of X-rays.
The whole machine is compact, portable,
easy to operate, safe and reliable,
and can be used for X-ray photography
in various hospitals, clinics, wards or operating rooms.
| Main technical indicators | |
| Power supply conditions | Voltage: 180-240V Frequency: 50Hz Internal resistance: ≤ 1 Ω Current: A large photography volume of 22A |
| Timer | 0.08-6.3s 20 speed electronic |
| X-ray machine head focus to the highest position of the plane | >1820mm |
| X-ray machine head focus to the lowest position of the plane | >550mm |
| Optical center positioning beam device | Film with a focal length of 1000mm Maximum size is 430 x 430mm |
| Remote control maximum distance | >6M |
| X-ray tube focus | 2.6 x 2.6 |
| Machine movement force | <5kg |
| Net weight of the entire machine | 90kg |
