mobile bedside X-ray machine (MST-X50AY)
Tel：
0754-88481863Product Introduction:
This machine is a mobile bedside X-ray machine that
adopts full wave rectification and a combination X-ray head.
The frame adopts a cantilever structure, and
the head positioning is light and convenient.
This machine adopts an electric beam limiter,
which can conveniently
and correctly control the radiation field of
X-rays. The whole machine is compact,
portable, easy to operate, safe and reliable,
and can be used for X-ray photography
in various hospitals, clinics,
wards or operating rooms.
| Main technical indicators | |
| Power supply conditions | Voltage: 180-240V Frequency: 50Hz Internal resistance: ≤ 1 Ω Current: 15A higher photography output |
| Timer | 0.08-6.32 electronic mode |
X-ray machine head focus to the highest position of the plane | >1820mm |
X-ray machine head focus to the lowest position of the plane | >550mm |
| Optical center positioning beam device | Film with a focal length of 1000mm Maximum size is 430 x 430mm |
| Remote control maximum distance | >6M |
| X-ray tube focus | 2.3 x 2.3 |
| Machine movement force | <5kg |
| Net weight of the entire machine | 90kg |
