Auto-x-ray film processor (MST-H14A)
Tel：
0754-88481863MST series X-ray Auto Processor is a compact,automatic table-top processor.
The Film mataerials are developed,fixed,rinsed and dried.
The film processor has been fitted with an automatic film-registration and
a stand-by mode.
The developing solutions are temperature-regulated,circulated and
automatically replenished.
Developed film size: 3"x4"'14"x17"
MAX.Developing width: 435mm(14")
Channel volume: Developer 6L, Fixer 6L,Water 6L
Developing speed: 90'450S at option
Developing temp: 20℃'40℃ at option
Developoing capacity: 220pcs/h
Power Source: 220-240V8.8A50/60HZ
Power: 1.5kw
Weight: 70kgs(N.W) 110kgs(G.W)
Dimensions(LxWxH): 92x64x120cms
