Medical Endoscopic Camera System (E22A)
Tel：
0754-88481863Main Features
1.Sony CMOS FHD Camera
2. Built-in LED Cold Light Source
3. Additional HD Medical Monitor can be connected via HDMI video output
4. Recording function can be achieved
5. Built-In USB Recording and Storage
6. Suggest to be used for all rigid endoscopes, such as rigid (ENT) otoscope, laryngoscope,
sinoscope, laparoscope, hysteroscope, cystoscope, arthroscope, spine endoscope etc.
This model will have a good surgery performance.
| Models | E22A | ||
| Image sensor | 1/2.8” 1/1.8'' COMS | Touch Screen | 7 inch, E22B(display function) |
| Resolution | 1920x1080p | Storage | U disk or Hard disk |
| Color | 3500k/6500k/7500k | Color Temperature | 5700-7000K |
| Replay | Video and Picture | Photograph | 2 megapixel JPG |
| Product size mm | Width 38mm x Height 12mm x Length 32mm | Video signal output | HD-SDI，HDMI, USB,DVI,CVBS |
| Life span of LED | 50,000Hours | Net Weight kgs | 5.8kgs |
| Color rendering index | >90 | Illumination Intensity: | > 2,000,000 Lux |
